Commutateurs - switch - emidax - 5v dc, 9v dc, 12v dc output - gp-101st

HARDWARE Ports 1 Port RJ-45 10/100/1000Base-T PoE Input Port
1 Port RJ-45 10/100/1000Base-T Output Port
1 Port DC Jack Output Port LED Indicators 5V/9V/12V, Power and AC Power Input IEEE 802.3af, IEEE 802.3at Power Output DC Out Adjustable Slide Switch for Either 5V/2A, 9V/2A or12V/2A DC Output Power
Y-Cable DC Pin (ODxIDxL) : 5.5 x 2.1 x 9.5 mm and 3.5 x 1.35 x 11 mm Pin Assignment 1/2(+), 3/6(-) End-Span (mode A) or 4/5(+), 7/8(-) Mids-Span (Mode B) Dimensions (L x W x H) 63 × 64 × 23 mm Weight 65g ENVIRONMENT Temperature Operating: 0 ~ 40℃
Storage: -40 ~ 70℃ Humidity (Non-condensing) Operating: 10 ~ 90%
Storage: 5 ~ 90% STANDARDS COMPLIANCE Standards IEEE 802.3 10BaseT Ethernet
IEEE 802.3u 100BaseTX Fast Ethernet
IEEE 802.3ab 1000BaseT Gigabit Ethernet
IEEE 802.3af Power Over Ethernet (PoE)
IEEE 802.3at Power Over Ethernet Plus (PoE+) Certifications FCC, CE

PACKAGE CONTENTS

• GP-101ST PoE+ Splitter
• One DC Y-Cable
• Quick Installation Guide
