Commutateurs - switch - JHA-IGS12 - 2 ports 10/100/1000TX et 1 slot SFP 1000X - Ethernet industriel non géré - boîtier IP40

Obtenir un devis / prix
Prix et détails sur demande
Shenzhen JAI Technology Co., Ltd
Echanger avec le vendeur
Commutateurs - switch - JHA-IGS12 - 2 ports 10/100/1000TX et 1 slot SFP 1000X - Ethernet industriel non géré - boîtier IP40_0
Commutateurs - switch - JHA-IGS12 - 2 ports 10/100/1000TX et 1 slot SFP 1000X - Ethernet industriel non géré - boîtier IP40_1

Description

Caractéristiques principales :

  • 2 ports 10/100/1000Base-T(X) et 1 slot 1000Base-X SFP
  • Support des normes : IEEE802.3, IEEE802.3u, IEEE802.3x
  • Plug-and-play, auto-adaptation MDI/MDI-X
  • Protection industrielle : ESD 15kV, surtensions 8kV
  • Température de fonctionnement : -40 à 85°C
  • Boîtier en alliage d'aluminium classé IP40, montage sur rail DIN
  • Alimentation redondante : DC10-58V

Introduction :

Le JAI-IGS12 est un commutateur Ethernet industriel non géré, plug-and-play, conçu pour fournir une solution économique et fiable pour les réseaux Ethernet dans des environnements industriels difficiles. Il est doté d'une structure robuste et totalement étanche (protection IP40), résistante à la poussière, aux surintensités, aux surtensions et aux interférences électromagnétiques (CEM). Ses caractéristiques incluent une double alimentation redondante et un système d'alarme intelligent intégré pour une surveillance optimale du réseau.

Spécifications techniques :

Protocole et normesIEEE802.3, IEEE802.3u, IEEE802.3x
Contrôle de fluxIEEE802.3x, contrôle de flux par contre-pression
Performances de commutation
  • Taux de transfert : 7.44Mpps
  • Mode de transmission : Store and Forward
  • Taille du tampon de paquet : 1M
  • Bande passante du backplane : 10Gbps
  • Taille de la table MAC : 8K
Temps de retard100 000 heures
Garantie5 ans

Informations sur la commande :

ModèleDescription
JAI-IGS12Unmanaged Industrial Ethernet Switch, 1 1000Base-X SFP Slot et 2 10/100/1000Base-T(X), sur rail DIN, DC10-58V, -40 à 85°C Température de fonctionnement
JAI-IG12Unmanaged Industrial Ethernet Switch, 1 1000Base-FX et 2 10/100/1000Base-T(X), SC Connecteur multimode à double fibre, 550m, rail DIN, DC10-58V, -40 à 85°C Température de fonctionnement
JAI-IG12-20Unmanaged Industrial Ethernet Switch, 1 1000Base-FX et 2 10/100/1000Base-T(X), LC Connecteur mode unique, à double fibre, 20 km, sur rail DIN, DC10-58V, -40 à 85°C Température de fonctionnement
JAI-IG12W-20Unmanaged Industrial Ethernet Switch, 1 1000Base-FX et 2 10/100/1000Base-T(X), LC Connecteur mode unique, à l'unité de fibres, de 20 km, sur rail DIN, DC10-58V, -40 à 85°C Température de fonctionnement

Options disponibles :

  • Connecteurs fibre : SC/ST/FC/LC (SFP Slot), modes simple/multimode, double fibre/fibre unique, distances de 550m à 120km
  • Alimentation : DC24V DIN-Rail ou adaptateur secteur
