Description

5 10/100TX PoE/PoE+ | Unmanaged Industrial PoE Switch JAI-IF05P
Brève description :
5 ports non géré Industrial PoE Switch, avec 4 10/100Base-T (X) IEEE802.3af/à PoE/PoE+ Port et 1 10/100Base-T (X) Port Ethernet.
  • Support 4 10/100Base-T (X) PoE/PoE+ port et 1 10/100Base-T (X) port Ethernet.
  • Soutien IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af/à.
  • Soutien IEEE802.3af, alimentation maximale 15,4W.
  • Soutien IEEE802.3at, alimentation maximale de 30W.
  • Conception de puce industrielle, protection ESD 15kV, protection contre les surtensions 8kV.
  • DC48-58V puissance de redondance, de polarité inverse.
  • Qualité industrielle 4 conception, -40 à 85 °C température de fonctionnement.
  • Boîtier en alliage d'aluminium classé IP40, monté sur rail DIN.

Introduction :
Le JAI-IF05P est un switch industriel PoE non géré plug-and-play. Ce commutateur fournit 5 ports Ethernet 10/100Base-T (X), dont 4 ports avec fonction Power over Ethernet (PoE) (IEEE802.3af/at).
Les commutateurs sont classés comme équipement de source d'alimentation (PSE). Lorsqu'ils sont utilisés de cette manière, ils permettent la centralisation de l'alimentation, fournissant jusqu'à 30 watts de puissance par port et réduisant l'effort nécessaire pour l'installation électrique.
Les commutateurs peuvent être utilisés pour alimenter des appareils standard IEEE802.3af/à (PD), ce qui élimine la nécessité d'un câblage supplémentaire.
Le JAI-IF05P prend en charge les normes CE, FCC et RoHS. Il adopte une conception standard industrielle avec protection IP40, boîtier robuste en métal résistant, entrée de puissance (DC48-58V). Le switch prend en charge IEEE802.3, IEEE802.3u, IEEE802.3x avec 10/100Base-T (X), intégral/semi-duplex et MDI/MDI-X auto-adaptation. Avec une plage de température de fonctionnement de -40 à 85 °C, il répond à tous types d'exigences industrielles, offrant une solution fiable et économique pour votre réseau Ethernet industriel.
Spécifications :
Protocole/NormeIEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af/à
Contrôle de fluxIEEE802.3x, contrôle de flux de contre-pression
Performances de commutationTaux de transfert : 1.19Mpps
Mode de transmission : Store and Forward
Packet Buffer Size : 512K
Système Exchange Bande passante : 1.6Gbps
MAC Taille de la table : 1K
Temps de retard100.000 heures
Garantie5 années

Informations sur la commande :
Modèle No.Description des biens
JAI-IF05PUnmanaged Industrial PoE Switch, 4 10/100Base-T (X) PoE/PoE+ et 1 10/100Base-T (X), sur rail DIN, DC48-58V, -40 à 85 °C Température de fonctionnement. Alimentation : DC48V DIN-Rail ou adaptateur secteur en option.
